LD Mobile Station

Portable roadside sensing workstation

LD Mobile Station

The LiangDao Mobile Station is a set of roadside sensing workstations that can be deployed flexibly. It is equipped with perception algorithms to detect real-time traffic objectives.

The hardware part of the mobile station can flexibly match different types of sensors, such as LiDAR, radar, camera. It features a revolutionary 360° scanning design with 90° vertical FOV. Its power is supplied independently. At the same time, it has an electric lifting function for easy operation by a single person, which make the Station be able to meet the requirements of different height application scenarios.

Application scenarios

  • Ground truth
    acquisition
  • Digital-twin
    simulation
  • Perception
    testing
  • Traffic flow
    detection
  • Teaching
    facility
  • APA testing

Specifications

Operating Environment

  • Operating Temperature
    -20℃~+60℃
  • Protection Class
    IP67

Performance

  • LiDAR Horizontal FOV
    360°
  • LiDAR Vertical FOV
    0°~-90°
  • Camera Horizontal FOV
    360°
  • Camera Vertical FOV
    55.9°
  • Detection Range
    Radius 50~150m

Interface and others

  • Interface
    Wired/Wireless Network
  • Wireless Standard
    5G

Mechanical

  • Size
    105*696*2300mm
  • Lifiting Range
    2.3~5.3m
  • Operating Voltage(lifter)
    220v
  • Power Consumption
    Electric lifter 380W ; others 100W
  • Weight
    225kg
  • Wind Resistance
    5 level

Use Cases

  • Krefeld Sustainable Mobility Project
    By deploying LDMobile Station, Liangdao provides the city of Krefeld, Germany with real-time detection of all movements of key road users (including vehicles, bicycles, trucks, vans, motorcycles and pedestrians) at the entire intersection, and provides accurate analysis and planning data of traffic flow to help improve road safety.
  • Winter Olympics Intelligent 5G Park Project
    Under the existing 5G network intelligent vehicle networking system in Shougang Park, in order to achieve higher accuracy of the objects, they planned to select a single intersection in Shougang Park to acquire high precision target data, traffic statistics and other functions within the intersection by obile points.
